Much has changed in how LINSTOR® is typically deployed into Kubernetes clusters over the years. I’m referring to the LINSTOR Operator for Kubernetes which is now at a v2 release, but the CSI plugin is still the bridge between Kubernetes and LINSTOR-managed replicated block storage. While LINBIT® encourages its customers and users to use the LINSTOR Operator for deploying containerized LINSTOR clusters into Kubernetes, you can run LINSTOR outside of Kubernetes with only the LINSTOR CSI plugin components running in Kubernetes.
There is plenty of documentation around how the LINSTOR Operator can help you easily deploy LINSTOR in Kubernetes, however “CSI only” instructions aren’t discussed much outside of the CSI plugin’s GitHub repository. This blog post sheds light on this alternative architecture for when an administrator wants to deploy LINSTOR outside Kubernetes and integrate it with Kubernetes by using the CSI plugin.
Prerequisites and assumptions
To keep this blog as concise as possible, I’ll assume you already have done the following:
- Created and initialized a LINSTOR cluster
- Created a storage pool within LINSTOR
- Created and initialized a Kubernetes cluster
There are many options and paths available to satisfy the prerequisites above. I’ll assume that you created a 3-node LINSTOR cluster on the same nodes that you created and initialized the Kubernetes cluster on. I’ll also assume the LINSTOR storage pool that you made was an LVM_THIN type named lvm-thin, although it is possible to use a storage pool backed by ZFS.
❗IMPORTANT: The instructions in this article depend on LINSTOR running on the same nodes as your Kubernetes cluster. For the CSI plugin to communicate with LINSTOR running in a separate cluster, you would need to either install the DRBD® 9 kernel module and install and enable the LINSTOR satellite service on your Kubernetes nodes. You would then need to add the Kubernetes nodes as LINSTOR satellite nodes in the LINSTOR cluster. The Kubernetes nodes could then use the LINSTOR diskless attachment feature to access storage in the LINSTOR cluster, over the network, as if it was local storage. Or, you could use LINSTOR Gateway to create a highly available iSCSI, NVMe-oF, or NFS target from your LINSTOR storage to expose external LINSTOR-managed storage to the Kubernetes cluster.
Some verification commands and output confirming the prerequisites as used in the examples in this article follow:
# kubectl get nodes
NAME STATUS ROLES AGE VERSION
kube-0 Ready control-plane 4h41m v1.35.3
kube-1 Ready <none> 4h41m v1.35.3
kube-2 Ready <none> 4h41m v1.35.3# kubectl get nodes -o wide
NAME STATUS ROLES AGE VERSION INTERNAL-IP EXTERNAL-IP OS-IMAGE KERNEL-VERSION CONTAINER-RUNTIME
kube-0 Ready control-plane 4h42m v1.35.3 192.168.122.140 <none> AlmaLinux 9.7 (Moss Jungle Cat) 5.14.0-611.42.1.el9_7.x86_64 containerd://2.2.2
kube-1 Ready <none> 4h42m v1.35.3 192.168.122.141 <none> AlmaLinux 9.7 (Moss Jungle Cat) 5.14.0-611.42.1.el9_7.x86_64 containerd://2.2.2
kube-2 Ready <none> 4h42m v1.35.3 192.168.122.142 <none> AlmaLinux 9.7 (Moss Jungle Cat) 5.14.0-611.42.1.el9_7.x86_64 containerd://2.2.2# linstor node list
╭────────────────────────────────────────────────────────────╮
┊ Node ┊ NodeType ┊ Addresses ┊ State ┊
╞════════════════════════════════════════════════════════════╡
┊ kube-0 ┊ COMBINED ┊ 192.168.122.140:3366 (PLAIN) ┊ Online ┊
┊ kube-1 ┊ SATELLITE ┊ 192.168.122.141:3366 (PLAIN) ┊ Online ┊
┊ kube-2 ┊ SATELLITE ┊ 192.168.122.142:3366 (PLAIN) ┊ Online ┊
╰────────────────────────────────────────────────────────────╯# linstor storage-pool list
╭─────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────╮
┊ StoragePool ┊ Node ┊ Driver ┊ PoolName ┊ FreeCapacity ┊ TotalCapacity ┊ CanSnapshots ┊ State ┊ SharedName ┊
╞═════════════════════════════════════════════════════════════════════════════════════════════════════════════════════════════╡
[...]
┊ lvm-thin ┊ kube-0 ┊ LVM_THIN ┊ drbdpool/thinpool ┊ 30.39 GiB ┊ 30.39 GiB ┊ True ┊ Ok ┊ kube-0;lvm-thin ┊
┊ lvm-thin ┊ kube-1 ┊ LVM_THIN ┊ drbdpool/thinpool ┊ 30.39 GiB ┊ 30.39 GiB ┊ True ┊ Ok ┊ kube-1;lvm-thin ┊
┊ lvm-thin ┊ kube-2 ┊ LVM_THIN ┊ drbdpool/thinpool ┊ 30.39 GiB ┊ 30.39 GiB ┊ True ┊ Ok ┊ kube-2;lvm-thin ┊
╰─────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────╯Preparing and installing the LINSTOR CSI plugin
After you’ve initialized your Kubernetes and LINSTOR clusters, you can deploy the LINSTOR CSI plugin configuration into Kubernetes.
Entering the command that follows will download an example configuration from the LINSTOR CSI plugin’s GitHub repository. Replace every instance of the placeholder LINSTOR_CONTROLLER_URL string in the example, and apply the configuration to your Kubernetes cluster. Set the LINSTOR_CONTROLLER_URL string to the URL, including the DNS name or IP address and TCP port number, that points to your LINSTOR controller node’s REST API. By default, access to the LINSTOR controller node endpoint is via HTTP on port 3370. For a LINSTOR controller node with a DNS name of linstor-controller.example.com, the LINSTOR controller node’s REST API endpoint would be http://linstor-controller.example.com:3370. Therefore, you could use the following commands to update the appropriate string in the example configuration and deploy the LINSTOR CSI driver into Kubernetes.
LINSTOR_CONTROLLER_URL=http://kube-0:3370
kubectl kustomize https://github.com/piraeusdatastore/linstor-csi//examples/k8s/deploy \
| sed "s#LINSTOR_CONTROLLER_URL#$LINSTOR_CONTROLLER_URL#" \
| kubectl apply --server-side -f -💡 TIP: If you’ve configured your LINSTOR controller service for high availability by using DRBD Reactor, you should use the virtual IP address for your LINSTOR endpoint.
To verify the CSI driver deployment, enter the following command:
kubectl get pods --all-namespacesCommand output should show your LINSTOR CSI plugin pods running in the piraeus-datastore namespace:
NAMESPACE NAME READY STATUS RESTARTS AGE
[...]
piraeus-datastore linstor-csi-controller-5494bdd6f9-5t947 7/7 Running 0 3m1s
piraeus-datastore linstor-csi-node-2ng89 3/3 Running 0 3m1s
piraeus-datastore linstor-csi-node-6vjkc 3/3 Running 0 3m1s
piraeus-datastore linstor-csi-node-qvlzg 3/3 Running 0 3m1sDefining Kubernetes storage classes for LINSTOR
With your LINSTOR cluster integrated into Kubernetes, you can now define how you want LINSTOR persistent volumes to be provisioned by Kubernetes users. You can do this by using Kubernetes storage classes and the LINSTOR parameters specified on each.
LINSTOR storage classes, in their simplest form, contain the LINSTOR storage pool name and the number of replicas that LINSTOR should create for each persistent volume. The following example storage class definitions will create three separate storage classes defining 1, 2, and 3 replicas from the lvm-thin LINSTOR storage-pool.
cat << EOF > linstor-sc.yaml
---
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
name: "linstor-csi-lvm-thin-r1"
provisioner: linstor.csi.linbit.com
parameters:
linstor.csi.linbit.com/autoPlace: "1"
linstor.csi.linbit.com/storagePool: "lvm-thin"
reclaimPolicy: Delete
allowVolumeExpansion: true
---
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
name: "linstor-csi-lvm-thin-r2"
provisioner: linstor.csi.linbit.com
parameters:
linstor.csi.linbit.com/autoPlace: "2"
linstor.csi.linbit.com/storagePool: "lvm-thin"
reclaimPolicy: Delete
allowVolumeExpansion: true
---
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
name: "linstor-csi-lvm-thin-r3"
provisioner: linstor.csi.linbit.com
parameters:
linstor.csi.linbit.com/autoPlace: "3"
linstor.csi.linbit.com/storagePool: "lvm-thin"
reclaimPolicy: Delete
allowVolumeExpansion: true
EOFFinally, create the LINSTOR storage classes by applying the configuration:
kubectl apply -f linstor-sc.yamlEnter the following command to verify:
kubectl get storageclasses.storage.k8s.io # or `kubectl get sc` if you preferCommand output should show that you have three new storage classes defined in Kubernetes:
NAME PROVISIONER RECLAIMPOLICY VOLUMEBINDINGMODE ALLOWVOLUMEEXPANSION AGE
linstor-csi-lvm-thin-r1 linstor.csi.linbit.com Delete Immediate true 2m42s
linstor-csi-lvm-thin-r2 linstor.csi.linbit.com Delete Immediate true 2m42s
linstor-csi-lvm-thin-r3 linstor.csi.linbit.com Delete Immediate true 2m42sCreate a PVC and pod for testing your deployment
To test your deployment, define and create a PVC in Kubernetes specifying one of the three storage classes created in the previous section. The following PVC manifest uses the 3-replica storageClass:
cat << EOF > linstor-pvc.yaml
---
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
name: demo-vol-claim-0
spec:
storageClassName: linstor-csi-lvm-thin-r3
accessModes:
- ReadWriteOnce
resources:
requests:
storage: 4Gi
EOFApply the configuration to your Kubernetes cluster:
kubectl apply -f linstor-pvc.yamlEnter the following command to verify that you have a LINSTOR-provisioned PVC in Kubernetes:
kubectl get persistentvolumeclaimsOutput should show the new PVC:
NAME STATUS VOLUME CAPACITY ACCESS MODES STORAGECLASS VOLUMEATTRIBUTESCLASS AGE
demo-vol-claim-0 Bound pvc-[...] 4Gi RWO linstor-csi-lvm-thin-r3 <unset> 63sVerify that you also have a LINSTOR-created resource backing the PVC by listing LINSTOR resources:
linstor resource listOutput should show a new LINSTOR resource with a name containing a UUID that matches the UUID of the PVC volume name in Kubernetes:
╭──────────────────────────────────────────────────────────────────────────────────────────────────╮
┊ ResourceName ┊ Node ┊ Layers ┊ Usage ┊ Conns ┊ State ┊ CreatedOn ┊
╞══════════════════════════════════════════════════════════════════════════════════════════════════╡
┊ pvc-[...] ┊ kube-0 ┊ DRBD,STORAGE ┊ Unused ┊ StandAlone(kube-2) ┊ UpToDate ┊ [...] ┊
┊ pvc-[...] ┊ kube-1 ┊ DRBD,STORAGE ┊ Unused ┊ StandAlone(kube-2) ┊ UpToDate ┊ [...] ┊
┊ pvc-[...] ┊ kube-2 ┊ DRBD,STORAGE ┊ Unused ┊ StandAlone(kube-1,kube-0) ┊ UpToDate ┊ [...] ┊
╰──────────────────────────────────────────────────────────────────────────────────────────────────╯After applying the configuration, you will have a LINSTOR-provisioned PVC in Kubernetes and a new, unused resource in LINSTOR.
Next, define and deploy a pod that will use the LINSTOR-backed PVC:
cat << EOF > demo-pod.yaml
---
apiVersion: v1
kind: Pod
metadata:
name: demo-pod-0
namespace: default
spec:
containers:
- name: demo-pod-0
image: busybox
command: ["/bin/sh"]
args: ["-c", "while true; do sleep 1000s; done"]
volumeMounts:
- mountPath: "/data"
name: demo-vol
volumes:
- name: demo-vol
persistentVolumeClaim:
claimName: demo-vol-claim-0
EOFApply the configuration to your Kubernetes cluster:
kubectl apply -f demo-pod.yamlVerify that the pod is up and running:
kubectl get pods -o wideOutput should show a running pod:
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
demo-pod-0 1/1 Running 0 58s 172.16.79.130 kube-2 <none> <none>Verify that the LINSTOR resource backing the PVC is now in use:
linstor resource listOutput should show the LINSTOR resource that backs the PVC associated with the pod is InUse on the node shown in the kubectl get pods output:
╭──────────────────────────────────────────────────────────────────────────────────────────────────╮
┊ ResourceName ┊ Node ┊ Layers ┊ Usage ┊ Conns ┊ State ┊ CreatedOn ┊
╞══════════════════════════════════════════════════════════════════════════════════════════════════╡
┊ pvc-[...] ┊ kube-0 ┊ DRBD,STORAGE ┊ Unused ┊ StandAlone(kube-2) ┊ UpToDate ┊ [...] ┊
┊ pvc-[...] ┊ kube-1 ┊ DRBD,STORAGE ┊ Unused ┊ StandAlone(kube-2) ┊ UpToDate ┊ [...] ┊
┊ pvc-[...] ┊ kube-2 ┊ DRBD,STORAGE ┊ InUse ┊ StandAlone(kube-1,kube-0) ┊ UpToDate ┊ [...] ┊
╰──────────────────────────────────────────────────────────────────────────────────────────────────╯Conclusion
Hopefully, you’ve found this information helpful in your quest to deploy LINSTOR outside of Kubernetes. Again, if you’re new to LINSTOR in Kubernetes, LINBIT recommends starting your testing by using the LINSTOR Operator for Kubernetes. If you have any questions about either approach, the LINBIT team is always available to talk with their users and customers. All you have to do is reach out.
Changelog
2026-04-10:
- Technical review and update.
- Added mentions of alternative disaggregated deployment options for integrating LINSTOR outside of Kubernetes.
- Replaced screen grabs with commands and command output in code blocks.
4GPVC storage size changed to4Gito align with binary storage size units used by DRBD.- Updated and verified links and URLs.
- Made language touch-ups.
